| Engine model |
380 |
385 |
480 |
485 |
4L22 |
490 |
496 |
4D33 |
4D38 |
4C39 |
4C41 |
6C58 |
6C61 |
6D71 |
6D75 |
| Type |
Vertical, In-line, four-stroke, water-cooled |
| Cylinder No-Bore × Stroke (mm) |
3-80x90 |
3-85×90 |
4-80×90 |
4-85×90 |
4-85×95 |
4-90x100 |
4-96×105 |
4-100x105 |
4-102X115 |
4-102×118 |
4-105×118 |
6-102×118 |
6-105×118 |
6-110x125 |
6-113×125 |
| Displacement (L) |
1.357 |
1.532 |
1.809 |
2.043 |
2.156 |
2.545 |
3.04 |
3.298 |
3.76 |
3.856 |
4.087 |
5.785 |
6.13 |
7.127 |
7.521 |
| Compression Ratio |
18:1 |
17:1 |
|
17.5:1 |
17:1 |
17:1 |
| Rated power (kW/hp) |
19/25.88 |
24/33.7 |
27.2/37 |
31/42 |
34/46 |
44/59.8 |
50/68 |
54/73.4 |
66/90 |
70.6/96 |
74/100 |
103/140 |
107/145.5 |
125/170 |
132/179.5 |
| Rated speed (r/min) |
3000 |
2900 |
2900 |
| Min. Fuel consumption under full loading (g/kW·h) |
≤270 |
≤238 |
≤270 |
≤247 |
≤238 |
≤248 |
≤238 |
≤235 |
≤235 |
≤221 |
≤231 |
≤248 |
≤248 |
≤231/227 |
≤227 |
| Max. torque/speed (N·m/rpm) |
78.4/2100 |
85/2350 |
104.8/2200 |
115/2400 |
120/2400 |
165/2200 |
175/2200 |
201/2200 |
245/2200 |
245/2200 |
265/2000 |
353/1600 |
402/1800 |
411/461 |
510/1800 |
| Lubrication Type |
Pressure & Splash |
| Starting Method |
Electric starting |
| Direction of rotation |
Counter-clockwise (Viewed from flywheel end) |
| Net weight (kg) |
290 |
300 |
330 |
335 |
335 |
360 |
380 |
400 |
430 |
430 |
430 |
580 |
590 |
750 |
760 |
| Standard equipment |
Silencer, Air cleaner, Radiator, Solenoid |
| Option equipment |
Battery, Control box and Fuel tank etc. are available on requirement |
| Applications |
Water pump set, Fire-fighting pump,Engineering machinery etc. |
