Tractor

Tractor Engine Specification List A
Model LL380BT KM385BT LL388BT KM390BT LL480BT 4L22BT 4L23BT KM490BT
Type 3-cylinder, in-line, Water cooled, 4-stroke 4-cylinder, in-line, Water cooled, 4-stroke
BoreStroke (mm) 8090 8590 8895 90x100 8090 8595 8895 90100
Piston Displacement (L) 1.357 1.532 1.73 1.909 1.809 2.156 2.311 2.545
Combustion  Type D.I. D.I D.I. D.I. D.I D.I. D.I. D.I.
Compression Ratio 6:01 6:01 6:01 6:01 6:01 6:01 6:01 6:01
Aspiration Type N.A N.A N.A N.A N.A N.A N.A N.A
Rated Power-speed (kW-r/min) 14.7-2350 18.4-2350 22.1-2350 23.6/2400 22.1-2400 25.8-2350 29.4-2400 29.5-2400
Fuel Consumption Rate (g/kW.h) 245 238 238 238 245 238 238 238
Max. Torque- Speed (N.m-r/min) 68-1680 85-2350 103-1700 108-1800 101-1680 121-1650 134-1800 135-1800
Emission level
Smoke (Bosch) 3 3 3 3 3 3 4 4
Noise ( dB(A) ) 110 110 109 110 110 110 110 110
Overall Dimensions LWH (mm) 567525610 589525610 567494610 600550650 687494610 695X494X620
Dry Weight (kg) 230 230 240 240 270 298 250 280
