Specification/ Model |
1105 |
1110 |
1115 |
KM130 |
KM138 |
LD24 |
LD26 |
LD28 |
KM160 |
KM173 |
KM186 |
|
Type |
Horizontal,4-stroke,D.I |
|
Bore x Stroke (mm) |
105*115 |
110*115 |
115*115 |
118*118 |
122*118 |
115*118 |
122*118 |
125*118 |
125*130 |
130*130 |
135*130 |
|
Displacement (L) |
0.995 |
1.093 |
1.194 |
1.29 |
1.38 |
1.225 |
1.38 |
1.448 |
1.595 |
1.732 |
1.861 |
|
Rated power/speed (12h) (kw/r/min) |
11.76/2200 |
13.24/2200 |
14.7/2200 |
16.2/2200 |
17.6/2200 |
15.3/2200 |
17.6/2200 |
18.38/2200 |
19.12/2200 |
22.06/2200 |
23.53/2200 |
|
Rated power/speed (1h) (kw/r/min) |
13.2/2200 |
14.7/2200 |
16.2/2200 |
17.6/2200 |
18.38/2200 |
17/2200 |
19.2/2200 |
20.2/2200 |
20.58/2200 |
23.53/2200 |
25/2200 |
|
Fuel consumption (g/kw.h) |
≤ |
≤242 |
≤242 |
≤242 |
≤242 |
≤242.1 |
≤252 |
≤252 |
≤252 |
≤252 |
≤252 |
|
Mean effective pressure (kPa) |
640 |
640 |
740 |
677(12h) 746(1h) |
660(12h) 726(1h) |
757 |
759(12h) 696(1h) |
760(12h) 691(1h) |
654(12h) 704(1h) |
779(12h) 830.9(1h) |
772.9(12h) 821.2(1h) |
|
Min. idle steady speed(r/min) |
≤800 |
≤800 |
≤800 |
≤800 |
≤800 |
≤800 |
≤800 |
≤800 |
≤800 |
≤800 |
≤800 |
|
Max. torque/speed (N.m/r/min) |
57.12/1650 |
64.2/1650 |
78.8/1650 |
85.6/1650 |
89.4/1650 |
82.7/1650 |
93.3/1650 |
98.2/1650 |
102.8/1650 |
114.4/1650 |
121.5/1650 |
|
Cooling method |
Water pump cooling &/or hopper cooling |
|
Starting method |
Hand cranking or electric starting |
Electric starting |
|
Lubricating type |
|
|
Overall dimensions (mm) (LxWxH) |
820*488*665 |
820*451*658 |
847*531*674 |
|
Net weight (kg) |
180 |
190 |
260 |
